SUCKER ROD ELEVA TORS
Sucker rod Elevators are the necessary tools to handle Sucker rod in
oil well repairing operation. The plate style rod elevators are
unique with interchangeable heat treated steel plates for different
size rods and ease of changing plates when worn to limit wear on
elevator body. The elevators are
designed and manufactured according to API Spec 8A-Specification for
Drilling and Production Hoisting Equipment.
|
model |
Sucker rod style (in) |
Elevator bores (mm) |
Max. Load (tons) |
Weight (kg) |
|
SE19 |
1/2 |
19 |
20 |
12 |
|
SE23 |
5/8- 3/4 |
23 |
|
SE26 |
3/4-7/8 |
24 |
|
SE30 |
1 |
30 |
|
SE32 |
1 1/8 |
32 |
|
model |
Sucker rod style (in) |
Elevator bores (mm) |
Max. Load (tons) |
Weight (kg) |
|
SE19 |
1/2 |
19 |
25 |
12 |
|
SE22 |
5/8- 3/4 |
23 |
|
SE26 |
3/4-7/8 |
24 |
|
SE30 |
1 |
30 |
Sucker
Rod Wrench
It
can change the plate style inserts to fit for different size of
rods.
•
Snap-Up, Hammer-Action
•
Balanced Design
•
Easily Serviced
|
Type GS |
Handling Rod Size (in) |
Max Torque (ft-lbs) |
Weight (lbs) |
|
5/8" |
700 |
44 |
|
3/4" |
|
7/8" |
|
1" |
Heavy lift short snap-in rod hook
Purpose: The special designed snap-in latch mechanism lets rod
elevator bail hook in without operator releasing latch and bail is
held secure in place until released.
Sizes and Capacities: The Model FH-25 has a rated capacity of 20
tons and the Model RH-25 has a rated capacity 25 tons in accordance
with API standards.
Suck
rod hook is composed of hook ,bail and locking assembly .The bail of
suck rod is able to get into the hook without opening the locking
arm After the bail is on right place ,locking arm reset (preventing
the bail of suck rod get out of hook )under the function of spring
which ensures the lifting safety of suck rod hook .In addition ,put
a bush on the spring in case the something gets into the locking
assembly and get the locking assembly lost the function .
|
Type |
RH-25(MK) |
RH-25 |
RH-35 |
FH-25 |
|
Max Related |
25tons(225kN) |
25tons(225kN) |
35tons(315kN) |
25tons(225kN) |
|
Hook Open Dimension |
1.7/8 in(47.6mm) |
1.7/8in (47.6mm) |
1.7/8in (47.6mm) |
1.7/8in (47.6mm) |
|
