While running in or pulling out tubular at oil rigs the
joints (tool joints) are tightened or loosened with the
help of manual tongs or power tongs.
Dies are the principal element in the manual tongs or
power tongs which carry out the job of gripping the tool
joints, before torque application. (Rollers or chain are
also used for gripping of tubular while using pipe
spinners)
SHINEQUIP manufactures tong dies out of best quality
alloy steel. The dies are case hardened to a desired
depth, while leaving the inner portion (core) ductile.
The hardened surface is highly resistant to wear and
exhibits quality gripping of tool joints. The inner
ductile core absorbs the shock of sudden impact and
heavy torque. The combined effect is efficient operation
in the long run. We make dies and inserts meet OEM
specifications.
Full Circle Slip Inserts are available for Canvins
“Advance” Spiders, Models
“B”, “C”, “C-HD”, “E”, and “G”
|
OEM PN# |
SIZE |
|
65622-100 |
3 1/2” slip body assembly |
|
65652-1 |
2 3/8” insert |
|
65652-2 |
2 7/8” insert |
|
65652-3 |
3 1/2” insert |
|
65623-100 |
4 1/2” SLIP BODY assembly |
|
65653-1 |
3 1/2” insert(tubing) |
|
65653-2 |
4”insert(tubing) |
|
65653-3 |
4 1/2”insert(tubing) |
|
65624-4.75 |
4 3/4” Solid slip body assembly |
|
65624-1 |
5” Solid slip body assembly |
|
65624-2 |
5 1/2” Solid slip body assembly |
TONG
DIES AND INSERT PACKAGE PARAMETERS
|
ITEM |
PN# |
Type |
WEIGHT(KG) |
Amount per PLY Wooden case（piece） |
GW (KGS) |
Dimension of case (mm) |
Volume（m³） |
|
1 |
45293А |
2 3/8" А |
0.45 |
1000 |
462 |
570×500×460 |
0.13 |
|
2 |
45293В |
2 7/8" В |
0.44 |
1000 |
452 |
570×500×460 |
0.13 |
|
3 |
45293С |
3 1/2" С, 102 4" Е |
0.16 |
3000 |
492 |
570×500×460 |
0.13 |
|
4 |
45209 |
45209 |
0.072 |
6000 |
444 |
570×500×460 |
0.13 |
|
5 |
65652-1 |
2 3/8" |
59.4 |
2 |
204 |
420 |
570×500×460 |
|
6 |
65652-2 |
2 7/8" |
57.4 |
1.65 |
252 |
427.8 |
570×500×460 |
|
7 |
65652-3 |
3 1/2" |
54.4 |
1.05 |
405 |
437.25 |
570×500×460 |
|
8 |
45209 |
45209 |
17.7 |
0.072 |
6000 |
444 |
570×500×460 |
|
9 |
55177 |
50-48-1 |
|
|
|
|
|
CURVED-FACE DIES FOR POWER ROD TONGS
|
Rod Size |
Type Die |
Part No. |
Size Inthes |
WEIGHTS |
|
Each oz. |
Per Doz.In Lbs. |
|
1.050” |
Buttress |
30726 |
3/8×1×1 7/16 |
3 |
2 |
|
1.315” |
Buttress |
30724 |
3/8×1×1 7/16 |
3 |
2 |
|
1.660” |
Buttress |
30723 |
3/8×1 3/4×1 7/16 |
3 |
2 |
|
1.900” |
Buttress |
30721 |
3/8×1 1/4×1 7/16 |
3 |
2 |
CURVED-FACE DIES FOR POWER TUBING TONGS
|
Tubing Size |
Type Die |
Part No. |
Size Inthes |
WEIGHTS |
|
Each oz. |
Per Doz.In Lbs. |
|
2 7/8” |
9T-Buttress |
27498-1 |
3/4×2×3 7/8 |
16 |
12 |
|
11T-Buttress |
27498-2 |
|
2 3/8” |
9T-Buttress |
27494-1 |
3/4×2×3 7/8 |
16 |
12 |
|
11T-Buttress |
27494-2 |
|
2 1/16”-2” |
8T-Buttress |
29311 |
3/4×1 5/8×3 7/8 |
12 |
9 |
|
1.900” |
7T-Buttress |
29312 |
3/4×1 5/8×3 7/8 |
12 |
9 |
|
1.660” |
5T-Buttress |
29313 |
1/2×1 1/4×3 7/8 |
8 |
6 |
|
1.315” |
4T-Buttress |
29378 |
1/2×1 ×3 7/8 |
6 |
4 1/2 |
CURVED-FACE DIES FOR POWER CASING TONGS
|
Casing Tong and Size |
Type Die |
Part No. |
Size Inthes |
WEIGHTS |
|
Each oz. |
Per Doz.In Lbs. |
|
“CTS”:3 1/2” |
Plain |
30923 |
3/8×1×3 7/8 |
6 |
4 1/2 |
|
“CTS”:4” |
Plain |
30846 |
3/8×1×3 7/8 |
6 |
4 1/2 |
|
“CTS”:4 1/2” |
Plain |
31175 |
3/8×1 ×1 7/15 |
3 |
2 1/4 |
|
“CTS”:4 1/2”
(Jaw) |
Plain |
30847 |
3/8×1×2 5/8 |
4 |
3 |
|
“CTS”:4 1/2”
(Bush) |
Plain |
30848 |
3/8×1×3 7/8 |
6 |
4 1/2 |
|
“CTS”:5”
(Jaw) |
Plain |
30849 |
3/8×1×2 5/8 |
4 |
3 |
|
“CTS”:5”
(Bush) |
Plain |
30850 |
3/8×1×3 7/8 |
6 |
4 1/2 |
|
“CTS”:5 1/2”
(Jaw) |
Plain |
30925 |
3/8×1×2 5/8 |
4 |
3 |
|
“CTS”:5 1/2”
(Bush) |
Plain |
30924 |
3/8×1×3 7/8 |
6 |
4 1/2 |
|
“CTS”:4 1/2-5”-5
〞-51/2” |
Plain |
30869 |
3/8×1×2 5/8 |
4 |
3 |
Including BJ Model “CTS”Casing and Tubing Tong, oil
country 45000,RS, RSX TUBING TONG,
|
Place of use |
Type of
Die |
Part No |
Size ,Inches |
WEIQHTS |
|
Each Oz |
Per Doz.In Lbs. |
|
BJ Type B Tongs
BJ Type DB Tongs made In 1965 and latter |
Blue
Diamond |
16402-6 |
1/2×1 1/4×5 7/8 |
12 |
9 |
|
pyramid |
16402-2 |
|
BJ Types SOD ,C,F and LF Tongs
Type DB Tongs Mid
Prior to 1965;
BJ power Casing Tong(4 1/2”-13 3/8”);Lamb power
Casing Tong |
Blue Diamond |
16401-6 |
1/2×1 1/4×5 |
9 |
6 3/4 |
|
Pyramid |
16401-2 |
|
plain |
16401 |
|
Short Die for BJ Type B Tongs with 1 1/4 ” Slot:
BJ Power Drill pipe Tong:
Echols Power Casing Tong |
Pyramld |
24768-2 |
1/2×1 1/4×3 7/8 |
8 |
6 |
|
Coarse |
24768-8 |
|
plain |
24768 |
|
Half Die for BJ Type B Tong with 1 1/4” Slot or
Short Die for BJ Types SOD, OB C F,LF Tongs with
1 1/4”Slots |
Pyramld |
24770-2 |
1/2×1 1/4×2 7/8 |
|
4 1/2 |
|
|
|
6 |
|
|
|
Half Die for BJ Types SOD,DB ,C F and LF Tongs
with 1 3/4 Slot |
Pyramld |
24769-2 |
1/2×1 1/4 ×2 7/16 |
5 |
3 3/4 |
|
|
|
|
Die Spacer for All Tongs with 1 1/4” Slot |
Blank |
24771 |
7/15×1 1/4×2 |
4 |
3 |
|
Tongs with 1”Slot” |
plain |
12512 |
3/8×1×5 3/4 |
8 |
6 |
|
Tongs with 1”Slot” |
plain |
15668 |
3/8×1×5 |
7 |
5 1/4 |
|
Tongs with 1”Slot” |
plain |
26212 |
3/8×1×4 1/4 |
6 |
4 3/4 |
|
BJ WilsonType ; Type MS and MS Back –up |
plain |
6209 |
3/8×1×1 15/16 |
3 |
2 |
|
BJ Powalrmatic(142 and up): Super.Powalrmatic &
Hydratorc Tongs 1.315”-4”w/1”Slots |
plain |
6473 |
3/8×1×3 7/8 |
6 |
4 1/2 |
|
4 1/8”-4 1/2”Pipe sizes of above power tongs |
pyramid |
24554-2 |
3/8×1×1 7/16 |
3 |
2 |
|
plain |
24554 |
3/8×1×1 7/15 |
3 |
2 |
|
BJ Types S and WS Tongs |
plain |
6472 |
3/8×5/8×1 15/16 |
1 1/2 |
1 1/4 |
|
BJ Type T Tongs |
plain |
11607 |
1/2×1/2×2 1/4 |
3 |
2 |
|
BJ Snapon Tubing Tongs; 1.660”-1.900” |
plain |
11607-4 |
1/2×1/2×1 5/8 |
2 |
1 1/2 |
|
2 3/8”-3 1/2” |
plain |
11607-3 |
1/2×1/2×2 |
2 |
1 3/4 |
Note: Die Gripping surface is made is following
configurations and can be manufactured as per customer
requirements. Add suffix for your requirement after
basic part No.
SLIP DIES
|
J-2160 |
SDS/SDML Drill Pipe Slip Insert 3-1/2" x 2-3/8" |
|
J-2161 |
SDS/SDML Drill Pipe Slip Insert 3-1/2" x 2-7/8" |
|
J-2162 |
SDS/SDML Drill Pipe Slip Insert 3-1/2" x 3-1/2" |
|
J-2163 |
SDS/SDML/SDXL Drill Pipe Slip Insert 4-1/2" x
3-1/2" |
|
J-2164 |
SDS/SDML/SDXL Drill Pipe Slip Insert 4-1/2" x 4" |
|
J-2165 |
SDS/SDML/SDXL Drill Pipe Slip Insert 4-1/2" X
4-1/2" |
|
J-2166 |
SDML/SDXL Drill Pipe Slip Insert 5" x 4-1/2" |
|
J-2167 |
SDML/SDXL Drill Pipe Slip Insert 5" x 5" |
|
J-2168 |
SDML/SDXL Drill Pipe Slip Insert 5" x 4" |
|
J-2169 |
SDML/SDXL Drill Pipe Slip Insert 5-1/2" x 5" |
|
J-2170 |
SDML/SDXL Drill Pipe Slip Insert 5-1/2" x 5-1/2" |
|
J-2619 |
CMSXL Circular Button |
|
J-2620 |
DCS Circular Button |
|
J-2625 |
DCS-L Circular Button 11" - 12-3/4" |
|
J-2626 |
CMSXL Circular Button 18-5/8" |
|
J-2627 |
DCS-L/CMSXL Circular Button |
|
J-2628 |
DCS/CMSXL Circular Button |
|
J-2630 |
DCS-L/CMSXL Circular Button |
|
J-2631 |
CMSXL Circular Button |
|
J-7624-A-4 |
Slip Insert c/w Cotter Type C safey clamp |
|
J-7624-A-21 |
Slip Insert c/w Cotter Type T safety clamp |
|
J-3310 |
MP Grip Die c/w Cotter Pin |
|
J-7613-A-81 |
DU Slip Insert 4-1/2" x 4-1/2" |
|
J-7613-FF-81 |
DU Slip Insert 4-1/2" x 4" |
|
J-7613-C-82 |
DU Slip Insert 4-1/2" x 3-1/2" |
|
J-7613-B-82 |
DU Slip Insert 4-1/2" x 2-7/8" |
|
J-7613-H-81 |
DU Slip Insert 5-1/2" x 5-1/2" |
|
J-7613-G-81 |
DU Slip Insert 5-1/2" X 5" |
|
J-7613-E-81 |
DU Slip Insert 5-1/2" x 4-1/2" |
|
J-7613-EE-81 |
DU Slip Insert 7" x 7" |
|
J-7613-DD-81 |
DU Reducer Insert 7" X 6-5/8" |
|
J-7613-Z-81 |
DU Slip Insert 7" x 5-1/2" |
|
J-7502-A-5069 |
TS-100 Slip Insert 3-1/2" |
|
J-7502-A-5070 |
TS-100 Slip Insert 2-7/8" |
|
J-7502-A-5071 |
TS-100 Slip Insert 2-3/8" |
|
J-7502-A-26 |
TS-100 Slip Insert 5-1/2" |
|
J-7502-D-26 |
TS-100 Slip Insert 5" |
|
J-7502-C-26 |
TS-100 Slip Insert 4-1/2" |
|
J-7502-G-26 |
TS-100 Slip Insert 4" |
|
J-7502-F-26 |
TS-100 Slip Insert 3-1/2" |
Tong
Dies Used for Power Tongs Specifications:
|
Use for Products
|
Pipe Size(in) |
|
XQ89/3YB
XQ89/3YC |
Thin |
89 (3-1/2") |
|
Middle-thick |
73 (2-7/8") |
|
Extra-thick |
60 (2-3/8") |
|
XY114/6YB |
Big arc |
89 - 141.5 (3-1/2" - 4-1/2") |
|
Small arc |
73 - 78 (2-7/8" - 3") |
|
XQ140/12Y |
Ⅰ |
73 - 78 |
|
Ⅱ |
89 - 114 |
|
Ⅲ |
121 - 156 |
|
Used for Product
|
Pipe Size (in) |
Use for Product |
Pipe Size (in) |
|
W-SDS Rotary Slips |
2-3/8" - 4-1/2” |
9" Drill Collar Slips
|
9" |
|
W-SDML Rotary Slips |
2-3/8" - 5-1/2” |
Casing Slips |
6-5/8" - 30" |
|
W-SDXL Rotary Slips |
3-1/2" - 5-1/2” |
WA-C Safety Clamps |
3-1/2" - 15-5/8" |
|
3-1/2 - 5 Rotary Slips |
3-1/2" - 5" |
WA-T Safety Clamps |
1-1/8" - 4-1/2" |
|
5 - 7 Rotary Slips |
5" - 7" |
QQP60-89/585Pneumatic Spider
|
2-3/8" - 3-1/2" |
|
W3-1/2 /75 (125) Rotary Slips
|
2-3/8", 2-7/8", 3-1/2” |
QQP60-89/675Pneumatic Spider
|
2-3/8" - 3-1/2" |
|
W5 /75 (125.200) Rotary Slips
|
4", 4-1/2", 5" |
QQP60-127/900 Pneumatic Spider
|
2-3/8" - 5" |
|
DCS-S Drill Collar Slips
|
3" - 4-7/8” |
Well Repair Manual Tongs
|
2-3/8" - 10-3/4" |
|
DCS-R Drill Collar Slips
|
4-1/2" - 7" |
B Manual Tongs |
3-3/8" - 12-3/4" |
|
DCS-L Drill Collar Slips
|
6-3/4" - 14" |
DB Manual Tongs |
3-1/2" - 17" |
|
WT Drill Collar Slips |
4-1/2" - 11-3/4" |
13-3/8 Casing Manual Tongs
|
13-3/8" |
|
8" Drill Collar Slips
|
8" |
Q13-3/8 - 30 Casing Manual Tongs
|
13-3/8" - 30 |
|
