Hook Blocks Design Features Joining traveling block and hook together reduces overall Length and can help satisfy the requirements of operating a top drive. The hook blocks conform to API Spec. 8C PSL1, and API monogram can be used.We have new Mc Kissick Tubing Block on quick supply.

TYPE

MAX LOADkN

PULLEY

ROPE OD

mm

Hmm

Wmm

WEIGHT

kg

QTY

ODmm

YG35-2

360

2

460

22

1340

280

340

YG60-3

585

3

610

22

1985

395

1220

YG70-3

735

3

610

26

2310

425

1760

YG90-3

900

3

610

26

2360

433

1860

YG110-4

1125

4

660

26

2420

600

2478

YG110-4-1

1125

4

762

26

2500

600

2560

YG135-4

1350

4

660

26

2790

525

2675

YG135-5

1350

5

762

26

2900

700

3200

YG160-4

1575

4

762

29

3075

600

3900

YG160-5

1575

5

762

29

2800

700

4400

YG180-5

1800

5

762

29

3100

700

4450

YG250-5

2222.6

5

914

32

3400

700

5435

YG250-5-1

2222.6

5

1120

29

3630

700

6240

YG35-2-1

300

2

460

19

1000

305

265

YG70-3-1

735

3

610

26

1750

425

1190

YG80-3-1

800

3

610

26

1745

429

1225

YG90-3-1

900

3

610

26

1735

433

1260

 SL Swivels



●Equipped with standard bails.

●The wash pipe and packing assembly are cartridge type and can be replaced on the floor without disconnecting the rotary hose and/or gooseneck..

●The gooseneck is provided with a outlet for wire line logging.

●Equipped with 4″API hose connection.

●The Swivels conform to API specification 8A and API monogram can be used.

type

SL60

SL70

SL90

SL110

SL135

SL160

SL180

SL225

Max static load kNlb

586(131733)

675(151740)

900202320

1125(252900)

1350303480

1575359680

1800(404640)

2250505800

Maxload of bearing100r/min

300

400

600

800

1000

1200

1200

1500

Max Pressure MPapsi

14

14

27.53932.5

21

355005

355005

355005

355005

Center tube  mmin

50(2)

50(2)

602.36

63.5(2 3/8)

572.24

572.24

76(3)

762.99

Thread connect to center tube

2 1/2 LP

2 1/2 LP

4-1/2″ FH-LH

3 LP

4-1/2″ REG-LH

4-1/2″ REG-LH

4-1/2″ TBC

6-5/8″ REG-LH

Thread connect to kelly

2 7/8REG

3 1/2 REG

6-5/8″ REG-LH

4 1/2 REG

6-5/8″ REG-LH

6-5/8″ REG-LH

6-5/8″ REG

6-5/8″ REG-LH

Dimension mmin





--



229163864890.2025.1225.51

217578166085.6330.7525.98



27401010860

107.8739.7633.86

 CROWN BLOCK

点击看大图

YPE

MAX LOAD

KN

OD OF ROPE

Inch

PULLEY

amount

TC10

135

5/8

3

TC20

225

4

TC35

360

7/8

5

TC60

585

TC70

675

TC80

800

TC90

900

1

6

TC110

1125

TC135

1350

TC160

1575

1 1/8

TC180

1800

TC225

2250

1 1/4

 ROTARY TABLE

●The pinion and gear are made of alloy steel.

●The master bushing is made form a steel casting.

●Pin transmission type is suitable for APl standard square Kelly or hexagonal Kelly roller bushing

●Effective lubrication and reliable seals are provided by design.

●The rotary tables conform to API specification 7K and the API monogram can be used.

    TYPE

Spec

ZP100

ZP125

ZP175

ZP205

ZP275

ZP375

       Max Torque

 KNM

8

12

13.7

22.5

27.5

32.5

Open OD mm

φ260

φ305

φ444.5

φ520

φ698.5

φ952.5

Transmission ratio

34

34

3.58

3.62

3.68

3.60

Max Load

 KN

900

1350

1350

3150

4500

5850

Max speed

R/min

300

300

300

300

300

300

Center distance

mm





1118

1353

1353

1353

DIMENSION mm



1270x890x378

2070x1238x591

2330x1435x648

2381x1600x699

3432x1797x712

WEIGHT

KGS



1250

3500

4700

5200

6702

























OIL RIG SHEAVE

1) Material: Q235B, Q345B, 35#, 45#

2) Groove surface quench: HRC45-55

3) Groove surface quench depth: ≥2mm

4) Max processing diameter: ≤2,000mm

5) Low production period

 Features of Traveling Block: ● Side plate of traveling block is made of thick section steel plate so that it is strong enough.. As lifting up and down empty elevator, wire rope is stretched that helps the drum of the drawwork to enwind the wire rope and the down speed of unloaded hook, extend the life of wire rope. The sheave grooves is undertaken middle-frequency quencher so as to extend operating life of sheaves. Working sheaves are assembled with double-conic bearing, wherein each bearing has its individual lubricating channel. Besides, sheaves and bearing are interchangeable with its matched crown block.
● Note: It can be designed and configured as the customers requirement. The travelling block meets the API Spec 8C ,is allowed to use the API Monogram.


Model

YC90

YC135

YC170

YC225

YC315*

YC315

YC450

YC585

Maximum hook load KN

90

135

170

2250

3150

3150

4500

5850

Sheave OD mm(in)

762(30)

915(36)

915(36)

1120(44)

1120(44)

1270(50)

1524(60)

1524(60)

Sheave number

4

4

5

5

6

6

6

7

Diameter of steel wire rope mm(in)

25(1)

29(1 1/8)

29(1 1/8)

32(1 1/4)

32(1 1/4)

35(1 3/8)

38(1 1/2)

42(1 5/8)

DimensionLWHmm

1500806
533

1800960
610

2100960
630

22941190
630

25571190
804

26801350
974

30751600
800

31001600
965

Weight kg

1810

2400

4585

3805

4848

6842

8135

9250
